The motor stator testing system adopts industrial control computers and DSP digital processing units, integrating testing of multiple items such as three-phase DC resistance, insulation resistance, power frequency withstand voltage, turn to turn withstand voltage, LCR inductance, thermistor, and rotation direction; Equipped with online communication function. It has the advantages of fast testing speed, high accuracy, convenient use, and good reliability. It is a comprehensive testing equipment for motor stators, and all test data can be saved, queried, and printed.
The motor stator testing system is used for performance testing of single-phase two-wire, single-phase three wire, and three-phase three wire stator systems. The testing system is controlled by an industrial computer, which collects, records, and stores various testing data and results. Users can query, analyze, and analyze the testing data as needed. The motor stator automatic testing system can automatically complete the inspection and testing of motor stator requirements online, and can be widely applied to various AC motors (single-phase, three-phase, asynchronous, synchronous), household appliance motors, DC motors, stepper motors, micro motors and other products.
The main features of the motor stator testing system are:
1. Open system architecture:
Adopting an open system architecture, software and hardware can be freely expanded according to customer needs. Even after product delivery, there is still reserved space and interfaces to add functionality, making it easy for users to transform or adjust product specifications, allowing customers to invest once and benefit in the long run.
2. Precision instrument system:
Unlike similar products that use a high-voltage cabinet mode, the measurement and testing instruments are composed of measuring and testing equipment. All test signals are generated by the instruments themselves, automatically measured, with high testing accuracy and speed. The fluctuation of the power grid affects the test results, making the test conclusions more accurate, stable, and reliable.
3. Efficient testing speed:
Adopting high-speed parallel serial port technology optimized for the system and pipeline testing technology, the testing speed reaches a relatively high level. Cooperating with dual station or multi station line control operation devices can further improve the efficiency of the production line.
4. Convenient remote control operation:
The fully digital operation interface, LCD display, intelligent interface, and assistance system greatly reduce the professional quality requirements for instrument operators, making operations simpler and faster.
