Product introduction
The Vacuum Switch Vacuum Degree Tester is mainly used to quantitatively measure the vacuum degree in various types of vacuum switch arc extinguishing chambers. It uses a single-chip computer as the main control unit, and the testing process is fully automated. In principle, it changes the method of calibrating similar products at home and abroad using current peak value, and uses ion charge for calibration, effectively suppressing the interference of pulse power supply during the testing process, making the testing more stable and reliable.
Product Parameters
| Test object | Various types of vacuum switch tubes |
| Test method | Non-disassembly measurement of vacuum tubes using a new excitation coil |
| Scope of application | This instrument is a multi-purpose machine, which can measure various types of vacuum switches. |
| Measuring range | 10-5～10-1 Pa |
| measurement accuracy | 10-5～10-4 Pa,10% |
| 10-4～10-3 Pa,10% | |
| 10-3～10-2 Pa,10% | |
| 10-2～10-1 Pa,10% | |
| Magnetic field voltage | 1700V |
| Pulsed electric field high voltage | 30kV |
| Switch tube opening distance when testing
vacuum |
Normal use of open distance |
| Use environment | -20℃~40℃ |
| Host weight | 24kg |
| Dimensions | 410×320×370mm3 |
| Sampler | Magnetron coil |
How Accurate Is the UHV Vacuum Interrupter Test Set?
For vacuum circuit breaker manufacturers, measurement accuracy directly affects product quality control and factory acceptance testing.
UHV Vacuum Interrupter Test Set utilizes a proven magnetron discharge measurement method combined with high-speed digital signal processing technology to ensure accurate and reliable vacuum degree evaluation.
Key advantages include:
High measurement sensitivity
Stable test performance
Excellent measurement consistency
Reliable assessment of vacuum interrupter condition
Reduced influence of operator-related variations
The instrument is suitable for both incoming inspection of vacuum interrupters and final quality verification of completed vacuum circuit breakers.
Is the Tester Suitable for Production Line Testing?
Yes.
UHV Vacuum Interrupter Test Set is designed to support manufacturing and quality control processes throughout vacuum circuit breaker production.
Typical applications include:
Incoming inspection of vacuum interrupters
Production process quality control
Factory routine testing
Final product inspection
Type testing support
Quality assurance verification
Its simple operation and rapid testing process help manufacturers integrate vacuum testing into daily production workflows.
How Efficient Is the Tester for Batch Testing?
Production environments require high testing efficiency.
UHV equipment is designed to support:
Fast measurement cycles
Simplified test procedures
Automatic data processing
Quick result display
Continuous testing operations
Benefits for manufacturers include:
Increased testing throughput
Reduced operator workload
Improved production efficiency
Lower inspection time per unit
These features make the tester suitable for both small-batch and large-scale manufacturing operations.
Does the Tester Support Data Communication and Export?
Yes.
UHV Vacuum Interrupter Test Set provides multiple data management and communication functions to support modern manufacturing requirements.
Available functions include:
USB data export
Internal data storage
PC software support
Historical record review
Electronic report generation
These capabilities allow manufacturers to integrate testing data into quality management systems and production documentation processes.
How Does UHV Support Quality Traceability?
Quality traceability is becoming increasingly important for vacuum circuit breaker manufacturers.
UHV testers help establish complete testing records through:
Automatic storage of test results
Historical data management
Test report generation
Product inspection documentation
Electronic data archiving
Advantages include:
Product quality verification
Production batch tracking
Audit support
Customer acceptance documentation
Long-term quality record retention
By maintaining comprehensive test records, manufacturers can quickly trace product history, analyze quality trends, and strengthen overall quality control management.
Why Vacuum Circuit Breaker Manufacturers Choose UHV
Proven magnetron discharge testing technology
High measurement accuracy and consistency
Suitable for production line inspection and factory testing
Fast testing process for batch production
USB export and PC software support
Comprehensive data management and traceability functions
Factory quality documentation and technical support
OEM and customized solutions available
UHV Vacuum Interrupter Test Set provides vacuum circuit breaker manufacturers with an efficient and reliable solution for incoming inspection, production quality control, final testing, and long-term quality traceability, helping ensure consistent product performance and compliance with customer requirements.
